Research on the Application of the Pin Definition of Prefabricated Optical Cable in Smart Substation
-
摘要: 智能变电站的二次系统模块化建设技术,就是指采用模块化技术实现标准化设计工厂化加工、装配式建设,用以提升建设的整体效率和质量。装置之间、屏柜之间、预制舱或小室之间采用标准针脚定义的预制光电缆是二次系统模块化建设技术的重要组成部分。通过总结近3年模块化建设智能变电站的工程经验,本标准集中定义了智能变电站各间隔的场地智能控制箱至预制舱/二次及通信设备室上送光缆的光缆纤芯数、纤芯定义及排列,以实现后期智能变电站工程中预制电缆的标准化应用。Abstract: Modular construction technology of secondary system in intelligent substations refers to the use of modular technology to achieve standardized designing and factory processing, assembly-type construction, to enhance the overall efficiency and quality of construction. Prefabricated optical cables between equipments, cabins, and prefabricated cabin or chamber using standard sequence of pins are an important part of the modular construction technology. Summarizing the experience of modularized intelligent substation construction in recent 3 years, this standard focuses on the number and pins definition of prefabricated optical cables between intelligent cabinets and prefabricated cabin or secondary equipment rooms in Smart Substation, in order to achieve the standardization of prefabricated cable used in intelligent substation project.
-
Key words:
- smart substation /
- modular /
- standardization /
- prefabricated optical cables /
- bins definition
-
